The folks in Toyota's patent department had another busy year in 2024! The automaker secured more U.S. patents than any other automotive company for the 11th consecutive year. This is according to an annual patent report by the Intellectual Property Owners Association (IPO). Toyota also ranks 10th of all 300 companies listed. For reference:
- #10 Toyota
- #17 Hyundai
- #33 Ford
- #39 Honda
- #42 General Motors
- #71 Porsche
- #125 Nissan
Toyota secured 2,428 patents in 2024 a dip of 10 percent of 2023. Toyota says patents included innovations in cybersecurity, driver assist technology, edge computing, electric and fuel cell vehicles, mobility as a service, manufacturing, materials, robotics, telematics and V2V/V2X connectivity.
“Toyota is evolving into a mobility company, and the breadth and depth of our patent acquisitions exemplify the wide range of invention that is taking place at our company,” said Sandra Phillips, senior vice president, Enterprise Integrity, chief sustainability officer and chief legal officer at Toyota Motor North America. “It’s a collective effort from every part of Toyota including contributions from North America R&D, Toyota Research Institute, Toyota Connected, Woven by Toyota and our manufacturing centers.”
“Toyota takes a strategic approach to patent filing, ensuring that we are building a portfolio of core technology and supporting future goals and objectives,” said Fred Mau, Intellectual Property (IP) counsel and director of Patent Licensing for Toyota IP Solutions. “We are securing a tremendous amount of new IP in growth areas of electrification, new materials and autonomous driving.”
Here are some of the patents Toyota is highlighting:
- LiDAR Reflective Fabric – LiDAR-based obstacle detection and avoidance systems, most commonly used on autonomous vehicles, have historically not had effective visibility of black-colored items due to their lack of reflectivity. Toyota says it's previously received a patent for a proprietary black pigment based on copper oxide nanocrystals that enable detection by LiDAR. Now, Toyota says this pigment has been integrated into textiles that can be used in clothing, bags and apparel for improved LiDAR detection safety. INVENTORS: Michael P. Rowe, Songtao Wu, Debasish Banerjee, Charles R. Rutledge, Torin C. Peck and Michael Jones.
- Transport Energy Transfer using Real-time Cost Information – An electric vehicle (EV) with bi-direction power transfer capability is a useful source of distributed energy for the electric power grid. The power grid is not homogenous, and local supply-vs-demand imbalances are reflected in real-time electricity pricing at different locations at different times of the day. A bi-directional EV can charge and discharge power from/to the grid taking advantage of these local price differences. However, it becomes very difficult for the EV owner to track pricing and make decisions of when, where, and how much energy to charge or discharge. Toyota says it's developed a method to automate the tracking of this information and use it to optimize and recommend the time, location and amount of energy to charge and discharge for maximizing the energy value without impacting the mobility needs of the EV. This method is applicable to both commercial fleet vehicles as well as individual privately-owned vehicles. INVENTORS: Norman Lu and Maximilian Parness.
- Systems and Methods for Managing Cooperative Maneuvering Among Connected Vehicles – In order for automated vehicles to make future traffic more efficient, these vehicles will have to work together, or cooperate, by sharing their future plans through wireless communication. Depending on the traffic situation and the type of maneuver, an automated vehicle may ask different surrounding vehicles to cooperate. Toyota says it's created methods to select which vehicles are best to cooperate to produce more efficient and smoother flowing traffic. INVENTORS: Sergei S. Avedisov, Yashar Zeiynali Farid and Onur Altintas.
- Modular Fuel Cell System Architecture and A Control System for Distributing Power to The Modules – Toyota says hydrogen fuel cell systems represent an important technology for its multi-pathway approach for reducing carbon emissions. Toyota says it is evolving this technology with a new architecture and control system that optimizes power distribution for maintaining efficiency, durability, drivability and/or safety of the system. This equalizes power draw on the battery and can extend battery life. INVENTORS: Christopher M. Bulpitt, Daniel Charles Folick, Jared Farnsworth, Andrew Sata, Arlo C. Eitzer, Laura E. Bower, Daniel K. Lim, Jonathan J. Sander, Luke A. Rippelmeyer, Scott A. Friedman and Takehito Yokoo.
Photo: Toyota.
